Item Description
Specification: - Screen size:5 inch
Image sensor:3 Mega Pixels HD Sensor
Video output:1080P Full HD (via HDMI);720P (via PC)
Video format:real time play via HDMI w/o recording;MJPEG recording via PC Software
Magnification:Up to 560 times (HDMI monitor 22 inch)
Photo resolution:12M
Photo format:JPEG
Focus range:5cm to 12cm
Frame rate:Max 30f/s under 600 Lus Brightness
Video-output interface:HDMI/AV
Storage:Micro-SD card,up to 32G
Power source:5V DC
Light source:2 LED with the stand
Product Features
Make sure this fits. by entering your model number.
5 inch 1080P HDMI screen
Technical grade lens
Metal stand
Adjustable monitor
IR remote control
Package List
1 -Microscope
1 -Metal stand
1 -USB cable
1 -HDMI cable
1 -Adapter
1 -IR remoter
