Lattice USB download line FPGA CPLD ISP download simulation HW-USBN-2A
Login to Download: Download software
Features:
1. Using Lattice original design, to ensure the use of stable and reliable;
2. Support wide target voltage 1.2V- 5V;
3.USB power supply, no external power supply alone;
4. Supports all LATTICE development environments (LSC ISPVM, LATTICE DEMIOND, LATTICE ISPEVER, and LATTICE PROGRAMMER);
Supports a full range of Lattice FPGAs such as SC (M) / XP / XP2 / ECP2 (M) / ECP3 / ECP5 (G) / MachXO / MachXO2 / MachXO3 / ICE40 series;
6. Support Lattice full range of CPLDs, such as 1000/2000/4000 / ispMACH series;
7. Support JTAG, internal FLASH, SPI FLASH programming mode;
8. No need to install a separate driver, direct support for Diamond / ispLever6.x / 7.x / classic / ispVM various versions of drivers;
9. Has a current-limit input, ESD protection measures to ensure that the download line is complete;
10. Using Lattice official 2 * 5Pin pitch 2.54mm JTAG interface;
11. Support operating system Win2000 / XP, Windows7 / 8/10, Linux and so on
Download Wire Pin Description:
1.SCLK / TCK: connect with chip's SCLK / TCK pin;
2.GND: Downloader and the target board of the public, its internal 2,4-pin connection, in use, need to be a 2,4 feet connected to the target board;
3.MODE / TMS: with the chip's MODE / TMS pin connection;
4.GND: Downloader and the target board of the public, the internal 2,4-pin connection, in the need to use these two in a 2,4 feet connected to the target board;
5. SDI / TDI: SDI / TDI pin connection with the chip;
6.VCC: Used to detect whether the target board connected to the downloader is powered on or not used to power the target board. The official downloader does not have the ability to supply power to the target board. This needs attention;
7.SDO / TDO: SDO / TDO pin connection with the chip;
8.INTI: need to connect INTI pins when downloading and debugging some chips, not every chip needs to be connected;
9.TRST: In some chip download debugging need to connect TRST pin, not every chip needs to connect;
10.ispEN / Enable / PROG: It is necessary to connect the ispEN / Enable / PROG pins when downloading and debugging some chips, and not every chip needs to be connected.
Shipping list:
1.Lattice USB download cable (1)
2.USB 2.0 data cable (1)
3.10P 2.54MM spacing of the cable (1)
4.10P high-quality lattice special fly line (1)
5.2.54mm pitch 2X5 turn 8P standard definition line (1)
